10inch 4000W 55H V3 E-Scooter Hub Motor

10inch E-Scooter In-Wheel Hub Motor(55H) 4000W V3 Type

10inch 4000W Hub Motor specially designed for powerful electric scooters with disc brake, the max speed can reach 90-100km/h.

Motor Specification:

1. Motor Type: BLDC Hub Motor with Permanent Manget
2. Motor design: Double axle out with 10inch rim
3. Rim size:2.15-10
4. Matached Tire: 3.0-10, 3.5-10
5. Magnet Height: 55MM
6. of Pole Pairs: 16 paris
7. Rated Power: 4000W
8. Peak Power: 5100W
9. Rated Voltage: 72V
10. Speed: 90-100km/h
11. Max No-load RPM: 1400RPM
12. Max Torque: 170N.M
13. Max Efficiency:90%
14. Continious current:61A
15. Max current:90A
16. Brake type: Disc brake
17. Rear Fock width for installation: 200mm
18. Stator Holder material: Aluminium
19. Cross Section of Phase wire: 10 mm2
20. Hall sensor phasing angle: 120 degree
21. Temperature Sensor: Optional
22. Working Temperature: 70 degree, Peak 120 degree
23. Waterproof Grade: IP66
24. Color: Black
25. W./ G..W. : 14kgs / 15kgs
26. Package Size: 34*34*33CM
